Black Refrigeration Condensing Unit TAJ4519 LTAJ4519EHR

Brand Name : KUB

Model Number : TAJ4519

Certification : ce

Place of Origin : Shanghai, China

MOQ : 1

Price : 1500USD

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 1000 Set/Sets per Year

Delivery Time : 5-7works

Packaging Details : wooden

Type : COMPRESSOR

Compressor : 2HP

Warranty : 1 Year

Video outgoing-inspection : Not Available

Key words : refrigeration unit

Voltage : 380V/3Ph/50Hz

Brand : KUB

Packing : Wooden Case

Condenser : Air Cooled Condenser

MOQ : 1

Contact Now

Product descriptions from the supplier

OLTL200T Monoblock condensing unit 2hp cold room condensing unit

Model	Type	Specifications			Condensation temperature ( ℃)	Evaporation temperature ( ℃)
Model	Type	Specifications			Condensation temperature ( ℃)	-23	-18	-12	-6
OLTL100T	Roof-top Side insert	Compressor	1HP	Cooling capacity (Watt)	37.8	1368	1791	2368	3031
		Voltage	380V/3/50		43.3	1565	2112	2665	3444
		Condensation Air volume	1650m³/h		48.9	1337	1827	2368	3043
		Evaporating Air volume	1650m³/h	Input power (Watt)	37.3	852	959	1067	1161
		Motor Power	0.22kw		43.3	965	1080	1193	1269
					48.9	972	1094	1224	1323
OLTL200T	Roof-top Side insert	Compressor	2HP	Cooling capacity (Watt)	30	2300	2900	3500	5200
		Voltage	380V/3/50		40	1900	2400	3000	4400
		Condensation Air volume	2600m³/h		50	-	1800	2400	3600
		Evaporating Air volume	2600m³/h	Input power (Watt)	30	1214	1232	1210	1209
		Motor Power	0.27Kw		40	1624	1602	1621	1536
					50	-	2106	2040	1917
OLTL300T	Roof-top Side insert	Compressor	3HP	Cooling capacity(Watt)	30	3200	4000	4900	7100
		Voltage	380V/3/50		40	2800	3500	4300	6200
		Condensation Air volume	5500m³/h		50	-	2900	3500	5100
		Evaporating Air volume	5500m³/h	Input power (Watt)	30	1618	1642	1613	1612
		Motor Power	0.85Kw		40	2079	2051	2075	1966
					50	-	2527	2448	2300
OLTL400T	Side insert	Compressor	4HP	Cooling capacity (Watt)	30	4900	6000	7300	10700
		Voltage	380V/3/50		40	4200	5300	6400	9300
		Condensation Air volume	5500m³/h		50	-	4300	5300	7700
		Evaporating Air volume	5500m³/h	Input power (Watt)	30	2346	2381	2339	2337
		Motor Power	0.85Kw		40	3014	2973	3009	2851
					50	-	3740	3623	3405
OLTL500T	Side insert	Compressor	5HP	Cooling capacity (Watt)	30	5800	7200	8800	12800
		Voltage	380V/3/50		40	5000	6200	7600	11100
		Condensation Air volume	5500m³/h		50	-	5100	6300	9200
		Evaporating Air volume	5500m³/h	Input power (Watt)	30	2810	2813	2841	2908
		Motor Power	0.85Kw		40	3609	3521	3523	3612
					50	-	4509	4436	4462

Temperature	Volume	Storage capacity	Horsepower	Model	Temperature	volume	Storage capacity	Horsepower	Moodel
Temperature	m³	Ton	HP	OLT	Temperature	m³	Ton	HP	OLT
5-0℃	4-10	1-2	1	100Z	-15--18℃	3-5	0-1	1	100L
	10-22	2-4	2	200Z		5-12	1-3	2	200L
	22-33	4-7	3	300Z		12-20	3-5	3	300L
	33-45	7-10	4	400Z		20-30	5-7	4	400L
	46-60	11-15	5	500Z		30-42	7-10	5	500L

Black Refrigeration Condensing Unit TAJ4519 LTAJ4519EHR

Lead time

Quantity (sets)	1 - 1	2 - 10	> 10
Lead time (days)	20	25	To be negotiated

Selection Principles

1. Compressor capacity should be determined according to each evaporating temperature mechanical load multiplied by the total system operating time factor. In addition to special requirements, generally do not use the machine equipment.

Reciprocating piston compressors Freon

2. Selection, when the compression ratio is greater than 10 should be the two-stage compressor; Should be less than or equal to 10 single stage compression. Freon two-stage compression system generally should adopt a throttle in the middle of incomplete cooling.

3. Generally cold in some of the cooler, oil separators, condensers, liquid and other equipment should be with Freon refrigeration compressor cooling capacity to adapt.

4. Selection of Freon refrigeration compressors working conditions, working conditions shall not exceed the limit specified in Shenzhen cold storage companies.

5. Freon refrigeration cooling systems, heat recovery should be used in general circulation.

6. Refrigeration compressor operating hours, for 5 ~ 100t of cold, generally can be every day and night operation 12 ~ 16h.
